Advanced OEM Pipetting Module
Innovative self-contained pipettor with pressure-based design. Improves pipetting flexibility. Infinite volume range. Compact and lightweight design, allows a 9 mm tip-to-tip distance. Enhances reliability, reduces maintenance. Frictionless operation with no pistons, minimizing wear and tear. Tubeless design enabled by an internal air pump. Cost-efficiency, premium performance without the premium price tag.
Receive your quote directly from the manufacturer.
OEM Pipetting modules to simplify your system design
Simplify your fluidics design with the smallest, self-contained pipetting module available without compromising your system's performance.
Save space, weight, and cost
- Now with a user-friendly tip-eject option.
- No external pressure source is required.
- Units can be mounted on 9 mm centers.
- 40% of the size and 25% of the weight of current technology.
- Increase your dynamic dispense range from uL to mL in a single device.
- Closed loop pressure control (tunable PID) enables liquid level, tip, clog and bubble detection.
Our solution
We have developed a fully self-contained pipetting module that opens new possibilities in liquid handling. Precision dispense performance that matches or improves upon the performance of other pipettors while greatly reducing size and weight.
Leading performance in a compact package.
Dimensions: 97.2 mm x 16.9 mm x 72.1 mm (3.83 in x 0.67 in x 2.84 in)
Width at tip mandrel: 8.95 mm (0.35 in)
Weight: 100g (3.5 oz)
Precision:
- 200 to 1000 µL: < 1% CV
- 50 to 199 µL: < 2.5% CV
- 10 to 49 µL: < 3% CV
- 5 to 9 µL: < 5% CV
- 1 to 4 µL: < 10% CV
Brochures
OEM Pipetting Module datasheet
Explore the technical specification on the OEM Pipetting Module from IMI Life Sciences.
Evaluating the impact of tip choice, pressure, and time settings on pipetting
This resource outlines the technical details on how the Pipettor from IMI Life Sciences operates, the calibration process of the Pipettor, and a case study for calibration and precision measurement to select the desired settings for your application.
IMI OEM Pipettor: Using pressure for liquid level detection
Accurate liquid-level detection (LLD) can be crucial in automated liquid handling systems, particularly in fields like pharmacology with small samples. In this resource, explore the IMI OEM Pipettor - an accurate, fast, and reliable way to dispense samples for analysis.
A self-contained pipettor with infinite volume range
Shantanu Jani, Head of Product Management at IMI Life Sciences provides a comprehensive overview of the Advanced OEM Pipetting Module - a self-contained, pressure-based pipetting module designed to enable flexibility, reliability, and simplicity in your automated liquid handling.
