MSCT Probes

  |  1 reviews

Product Image
Request Pricing

Turn On Instant Requests

VEECO Instruments Inc.

Receive your quote directly from the manufacturer.

Average Rating: 3.7
1 Scientist has reviewed this product

5 out of 5
Ease of use
3 out of 5
After sales service
3 out of 5
Value for money
Silicon nitride probes for contact, fluid tapping mode and force measurement, with a variety of extremely low spring constants for high force sensitivity. Sharpened; 6 cantilevers 0.01-0.50N/m; Au Reflective Coating.

Tip Specification
Sharpened Microlevers

Geometry: Cast
Tip Height (h): 2.5 - 8.0µm
Front Angle (FA): 15 ± 2.5°
Back Angle (BA): 25 ± 2.5°
Side Angle (SA): 22.5 ± 2.5°
Tip Radius (Nom): 10nm
Tip Radius (Max): 40nm
Tip SetBack (TSB)(Nom): 4µm
Tip Set Back (TSB)(RNG): 3 - 5.5µm

Cantilever Specification
Au reflective coating

Material: Silicon Nitride
Thickness (t)(Nom): 0.55µm
Thickness (t)(RNG): 0.5 - 0.6µm
Back Side Coating: Gold Reflective

Product Overview

Product Image

MSCT Probes

Manufacturer VEECO Instruments Inc.

3.7 / 5.0 | 1 reviews
