Heating Chambers with Forced Convection - FED Series

Product Image
Heating Chambers with Forced Convection - FED Series
  • placeholder
  • Video Thumbnail

Heating chamber with mechanical convection.The FED Series is a true all-rounder. It has a virtually unlimited capacity and is at the same time particularly adaptable to the specific requirements of a large variety of testing applications. The enhanced time functions and the digitally controlled air turbine can be used to adjust ideal temperature parameters and recirculation air conditions.Heating Chambers with Forced Convection - FED Series Features: Electronically controlled APT.line™ preheating chamber assuring temperature accuracy and reproducible results  Temperature range of 5 °C (9 °F) above ambient temperature up to 300 °C (572 °F) MS controller with several timer functions Controller timer functions: delayed ON, delayed OFF, temperature dependent delayed OFF Di...Read more

Receive your quote directly from BINDER for Heating Chambers with Forced Convection - FED Series

=

Description

Heating chamber with mechanical convection.

The FED Series is a true all-rounder. It has a virtually unlimited capacity and is at the same time particularly adaptable to the specific requirements of a large variety of testing applications. The enhanced time functions and the digitally controlled air turbine can be used to adjust ideal temperature parameters and recirculation air conditions.


Heating Chambers with Forced Convection - FED Series Features:

  • Electronically controlled APT.line™ preheating chamber assuring temperature accuracy and reproducible results
  • Temperature range of 5 °C (9 °F) above ambient temperature up to 300 °C (572 °F)
  • MS controller with several timer functions
  • Controller timer functions: delayed ON, delayed OFF, temperature dependent delayed OFF
  • Digital temperature setting with an accuracy of one degree
  • Adjustable fan speed
  • Front ventilation flap side and rear exhaust duct Ø 50 mm (1.97 inch)
  • Independent adjustable temperature safety device class 2 (DIN 12880), with visual temperature alarm
  • RS 422 for use with optional GMP/GLP and FDA guideline 21 CFR Part 11 compliabt APT-COM™ DataControlSystem software
  • Units up to 115 liters (4.1 cu.ft.) are stackable
  • 2 chrome-plated racks
  • BINDER test confirmation
  • Available in the following sizes: 53, 115, 240, 400 and 720

Product Overview

Product Image

Heating Chambers with Forced Convection - FED Series

by BINDER







Receive your quote directly from BINDER for Heating Chambers with Forced Convection - FED Series
